Electrical
Voltage : 20V AC
Current : 5A (Max.)
Contact Resistance : 40mΩ max. (Initial)
Dielectric Withstanding Voltage : 100V AC/rms
Insulation Resistance : 100 MΩ min.
Operating Temp : -40℃ ~ +85℃
Mating Cycles : 10,000 cycles
Specification(Abbreviation)
Family: Waterproof
Interface: Top-Mount
PCB Mounting: Dual SMT
Circuits: 24
High Speed Support: USB 3.2 Gen 1 (5Gbps)
Center Height (mm): 1.58
Above PCB Height (mm): 3.76
